Load class according to EN 1433
Load class according to EN 1433
up to F 900
up to F 900
up to D 400
up to F 900
Nominal width | System size
Nominal width | System size
3000, 5000, 8000
100 – 500
100 & 200
100 & 150
Materials of the lower parts
Materials of the lower parts
Modified polypropylene (PP), 100 % recycled composite
Fibre-reinforced concrete
Modified polypropylene
Liquid-tight concrete as a precast reinforced concrete element
Angle housing
Galvanised steel or ductile iron edge rail with 40 x 40 mm insertion depth
Galvanised steel or stainless steel angle housing with 40 x 40 mm insertion depth
Cover variants
Retained ductile iron slotted top
– Ductile iron covers
– GUGI ductile iron covers
Integrated award-winning FIBRETEC heelsafe design
– Ductile iron slotted covers
– Ductile iron covers
Special characteristics
– Radial installations possible
– Large channels for retention
– Channel run without slotted top achievable, for example, under planted areas
– Cable installations can be threaded though throat voids of the channel
– SIDE-LOCK, boltless locking system
– 16 fixing points for cover/metre
– Large retention volume despite slim channel design
– Monolithic drainage channel
– Vandalism-proof
– Easy cleaning via the inspection box
– Irrigation and drainage system (EFD and ESD)
– Corrosion-free, modular design in a recurring, fixed grid as a handy “plug-in” construction- Boltless locking system SIDE-LOCK
– 16-fold fixing options for the cover per metre
– Uniform irrigation of the carriageway
– Extremely low throw height (8-10 cm) and throw range (30-40 cm) of the water jet
Gradient
– Constant depth
– Stepped fall
– Constant depth
– Built-in fall (150, 200, 300)
– Stepped fall
– Constant depth
– Stepped fall
